Hemo Vet

Overview Specification Support Documents

EKF Diagnostics’ Hemo Vet is a point-of-care hemoglobin (Hb) and hematocrit (HCT) analyzer designed to provide quantitative, lab-quality results in 25-60 seconds. The device uses the photometric azide methemoglobin method ensuring reliable results with high precision (CV <2%). Additionally, Hemo Vet also calculates hematocrit.

A backlit screen touch screen, a soft-load cuvette holder, and an integrated rechargeable battery make the Hemo Vet the ideal analyzer for veterinary clinic use and mobile settings. It features a bidirectional interface using a public standard protocol that allows direct integration with third-party software.

Hemo Vet allows a veterinarian to quickly assess the HCT and Hb concentration of any subject in the clinic or in the field, and enable rapid diagnosis of a particular disease state along with other clinical symptoms and initiate treatment.

Simple, accurate, and reliable hemoglobin and hematocrit test

Key features:

Hemoglobin and hematocrit results in one test
Easy to use
Evaluated for various species
Reliable in a wide temperature range
Adjustable display for different light conditions
Compact and light

Contact our specialists

Easy hemoglobin and hematocrit measurement in three steps:

1

Collect blood sample

2

Put microcuvette into analyzer

3

Result appears in 25-60 seconds

Frequently Asked Questions:

How often should the optic be cleaned?

Easy to use

User-friendly features minimize training time
Step-by-step instructions on the screen
Adjustable backlit touchscreen
User-selectable language menu
Soft-load cuvette holder minimizes the risk of contamination

Accurate and reliable

Operating ambient temperature 15 °C – 40 °C
Photometric azide methemoglobin method
Measuring range: 0-25.6 g/dL; 0-15.9 mmol/L
Imprecision: CV <2 %
Linearity: 0-20 g/dL: ±0.3 g/dL; >20 g/dL: ±0.7 g/dL
Calibrated to NCCLS reference method
Stored up to 4000 results
Control cuvette included

Practical and portable

Hemoglobin and hematocrit results from one sample available in 25-60 seconds (depending on the concentration)
Venous, arterial or capillary blood
Sample volume only 8 µl, depending on cuvette type
n.x.t. shape microcuvette minimizes air bubbles
Compact in size and weighing just 700g
No maintenance required. Auto self-test
Integrated rechargeable battery (100 hours)

Efficient data handling

Bi-directional interface using LIS2-A2 communication standard
Stores 4,000 patient results
Connect to PC via USB connector cable

Hemo Vet: Datasheet (EN EU Rev 1.0 10-2022)

Download

Connectivity at the point-of-care

EKF Link is an optional software platform that provides a flexible and secure method for connecting point-of-care devices to hospital and laboratory IT systems.

Real-time data and device management on one platform

EKF Link is a middleware solution that helps healthcare providers manage their point-of-care analyzers and associated data on one platform. A flexible and open solution that can be interfaced with most point-of-care analyzers, allowing real-time data management, including patient test results, QC results, operator management, and analyzer configuration.

Find out more about analyzer connectivity
